Spacious, Suave, and stylish, the M45 offers a unique blend of performance and comfort. Standard features include an ergonomically designed helm station, spacious seating options with custom dedicated storage, Fusion Satellite Ready AM/FM Stereo, as well as a wet bar with solid surface top, sink, and faucet. Add on the optional wakeboard tower and portable platform grill to complete you’re on the water adventures!
LOA W/SWIM PLATFORM 24'0"
BEAM 8'6"
FUEL CAPACITY 50GAL
MAX HORSEPOWER 350HP
Design a Monterey vessel that’s truly a one-of-a-kind masterpiece and know there will never be someone out on the water like you.
| Spec | US Unit | Metric Unit | Description |
|---|---|---|---|
| LOA W/Swim Platform | 24'0" | 7.32M | Length Overall, including add-on swim platform, not including bow rail or anchor roller |
| LOA w/Engines | 26'4" | 8.03M | Length Overall With Engines |
| Beam | 8' 6" | 2.59M | Width of hull at widest section including rubrail |
| Deadrise | 20° | 20° | Angle of keel measured at transom |
| Draft - Engine Up | 16" | 40.6CM | Depth of hull to lowest point, Engine trimmed up |
| Draft - Engine Down | 32" | 81.3CM | Depth of hull to lowest point, Engine trimmed down |
| Bridge Clearance W/Tower | 7'8" | 2.3M | Height from water to highest point on tower, normal load |
| Fuel Capacity | 50GAL | 189.3L | Capacity of fuel tank in gallons/liters |
| Water Capacity | 10GAL | 37.9L | Capacity of water tank in gallons/liters |
| Dry Weight | 4500LBS | 2041KG | Mass of boat with engine(s) and batteries, no fuel, water, waste, or gear |
| Max Persons | 14 (US) | 12 (CE) | Maximum Rated Persons Capacity |
| Max Persons Weight | 2100LBS | 900KG | Maximum capacity of people that can be safely carried in pounds/kilograms |
| Max Persons W/ Gear Weight | 3232LBS | 1267KG | Maximum combined capacity of people and gear that can be safely carried in pounds/kilograms |
| Max Power | 350HP | 261KW | Maximum horsepower for safe operation |
| Engine | Option | Standards and Options |
|---|---|---|
Bilge Compartment |
Automatic Bilge Pump |  |
| Bilge Hatch, Electrically Actuated | |
|
| Gel Coated Bilge Compartment | |
|
Canvas |
Bimini Top w/Embroidered Boot | |
Cockpit |
Cockpit Table w/ Pedestal & Vertical Mount Bases, Forward & Aft | |
| Cooler, 48 Qt Carry-On | |
|
| Courtesy Lighting, Blue/White, LED 12 V | |
|
| Drink Holders, Stainless Steel (10) | |
|
| Fiberglass Cockpit Liner w/Non-Skid & Self Bailing | |
|
| Grab Rails | |
|
| Stereo, Fusion Satellite Ready AM/FM/Bluetooth w/built-in iPod Dock, & (4) Rockford Fosgate 6.5" Speakers & Dash Remote | |
|
| Outlet, 12 V | |
|
| Storage, In-Floor Ski w/Gas Assisted Hatch Cover & Dry Deck | |
|
| Storage, Starboard Helm | |
|
| Transom Shower, w/Pressurized Water (Cold Only) | |
|
| Wet Bar w/Solid Surface Top, Sink, Faucet, Trash Receptacle & Storage | |
|
Electrical Systems |
Battery Switch, Dual w/2 Battery Trays | |
| Weatherproof Electrical System w/Individual Circuit Protection | |
|
Fuel Systems |
Double Clamped Fuel Lines | |
| Water Separating Fuel Filter | |
|
Head |
Flooring, Synthetic Wood | |
| Toilet (Porta-Potti) | |
|
Helm |
Compass | |
| Digital GPS Speedometer | |
|
| Instrumentation w/Fog Resistant Gauges & Low Glare Night Lighting | |
|
| MP3 Adapter | |
|
| Outlet, 12 V USB | |
|
| Steering Wheel, Black w/Silver Insert | |
|
| Steering, Power Assisted | |
|
| Steering, Tilt | |
|
| Switches, Lighted Weatherproof | |
|
Hull & Deck |
Air Assist Chine | |
| Barrier Coat Vinylester | |
|
| Boarding Ladder, Telescoping & Recessed, Bow | |
|
| Bow & Stern Eyes, Stainless Steel, w/SS Backing Plate | |
|
| Bow Hand Rails, Stainless Steel | |
|
| Bow Plate, Stainless Steel | |
|
| Cleats, Pull-up, Stainless Steel (8) | |
|
| Colored Hull | |
|
| Cooler Molded In, Bow | |
|
| Custom Hull Side Graphics | |
|
| Door, Walk-Thru at Helm | |
|
| Door, Walk-Thru at Transom | |
|
| Drain Plug, Brass Garboard | |
|
| Horn, Electric Flush Mount | |
|
| Lights, Docking | |
|
| Lights, Navigation, LED | |
|
| NMMA Certified | |
|
| Rub Rail, Heavy Duty w/Stainless Steel Insert | |
|
| Storage, Anchor w/Fiberglass Hatch (Drains Overboard) | |
|
| Storage, Transom Wakeboard w/Gas Assisted Hatch & Dry Deck | |
|
| Swim Ladder, Telescoping & Recessed, Stern w/Fiberglass Hatch | |
|
| Swim Platform, Integral | |
|
| Thru Hulls, Stainless Steel Above Waterline | |
|
| Transhield Cover | |
|
| Windshield, Curved Tempered w/Walk-Thru, Onyx Framed | |
|
Seating |
Aft Back to Back L-Lounge w/Fiberglass Bases & Sun Pad Conversion w/Recliner, Electrically Actuated | |
| Aft Facing Transom Seat | |
|
| Bow Seating w/Hinged Storage Skirts | |
|
| Bucket Seat, Swivel w/Slider & Flip-Up Bolster, Port & Starboard | |
|
| Seat Cushions w/Storage Compartments, Bow | |
|
Bilge Compartment |
Battery Charger w/Deck Plug (Standard in Australia) |  |
Canvas |
Bow & Cockpit Cover: Onyx | |
| Bow & Cockpit Cover: Rio | |
|
| Bow & Cockpit Cover: Royal Blue | |
|
| Bow & Cockpit Cover: Sapphire | |
|
| Bow & Cockpit Cover: Taupe | |
|
Cockpit |
Cockpit Inlay, Terra (Seadek. Requires Seadek Swim Platform Inlay) | |
Cockpit Inlay, Gray (Seadek. Requires Seadek Swim Platform Inlay)
|
|
|
| Forward Shower w/Pressurized Water (Cold Only) | |
|
| Premium Stereo Upgrade Package Includes (4) 6.5" Rockford Fosgate M2 Speakers w/Integrated LED Lights, 10" punch Subwoofer and 5 channel amplifier(Requires Dual Battery Option) | |
|
| Stern Mounted Stereo Remote | |
|
| Swim Platform Inlay, Terra (SeaDek) | |
|
Swim Platform Inlay, Gray (SeaDek)
|
|
|
| Cone Speakers with 2 Channel Amp For Tower (Wakeboard Tower & Stereo Upgrade Required) | |
|
| Woven Cockpit Flooring | |
|
Head |
Toilet, Pump-out Deck Fitting | |
Helm |
Simrad GO7XSE GPS/Chartplotter/Sonar w/Transducer/Integrated Engine Functions & Depthsounder | |
Hull & Deck |
Anchor Windlass Pre-Wire | |
| Anchor Windlass w/Anchor, Rope and Chain (Requires Dual Battery Switch) | |
|
| Colored Hull Bottom (Other Than Arctic Ice) | |
|
| Delete Graphics | |
|
| Phender Pro Holders (4) | |
|
| Portlight, In Head, w/Screen | |
|
| Ski Tow Pylon, (Removable) | |
|
| Underwater Lights, RGB LED | |
|
| Hybrid Tower, Black (Includes Bimini) | |
|
| Hybrid Tower, White (Includes Bimini) | |
|
Seating |
Filler Cushion, Bow | |
| Portside, Foward/Aft Facing Lounger | |
|
Under Water Gear |
Trim Tabs W/Indicators & Auto Retract | |
| Engine | Total HP | Ratio | Drive | Prop | Max MPH Range | GPH @ Cruise MPH | |
|---|---|---|---|---|---|---|---|
| Verado 250XXL DTS | 250HP | OB | Enertia Eco-19-SS | 46-50 | 11.6@33.9 | Download | |
| Verado 250XXL DTS White | 250HP | OB | Enertia Eco-19-SS | 46-50 | 11.6@33.9 | Download | |
| Verado 300HP DTS | 300HP | OB | Enertia Eco-20-SS | 52-56 | 10.0@35 | Download | |
| Verado 300HP-White DTS | 300HP | OB | Enertia Eco-20-SS | 52-56 | 10.0@35 | Download |
Showing 1 to 4 of 4 entries
*Consult your local dealer for catalyst engine requirements for your region.
