298 Super Sport

The 298 Super Sport combines the very best in luxury, technology, and performance, creating an experience that will change the way you think of power-boating. With a stable and comfortable 9 foot beam, the 298SS comes standard with a generous head compartment, and spacious aft sun-pad complete with flip-up backrest for lounging. Always versatile, the 298SS can be equipped with either a wet bar or an aft facing observer seat maximizing room and comfort and offers multiple seating configurations.

Build Your Custom Monterey 298SS

Design a Monterey vessel that’s truly a one-of-a-kind masterpiece and know there will never be someone out on the water like you.

Begin My Build
Photo Gallery
A Study In Luxury
Monterey In Motion
Capturing Performance, Speed, And Luxury
Sorry video not available.
A Work Of Art Is Best Viewed In Person
Specifications Review
Spec US Unit Metric Unit Description
LOA W/Swim Platform 29'0" 8.84M Length Overall, including add-on swim platform, not including bow rail or anchor roller
Beam 9'0" 2.74M Width of hull at widest section including rubrail
Deadrise 21° 21° Angle of keel measured at transom
Draft - Stern Drive Up 25" 63.5CM Depth of hull to lowest point, stern drive trimmed up
Draft - Stern Drive Down 37" 94CM Depth of hull to bottom of stern drive, trimmed down
Fuel Capacity 100GAL 378.5L Capacity of fuel tank in gallons/liters
Water Capacity 15GAL 56.8L Capacity of water tank in gallons/liters
Waste Capacity 11GAL 41.6L Capacity of waste tank in gallons/liters
Bridge Clearance W/Arch 8'7" 2.6M Height from water to highest point on arch, normal load
Max Persons Yacht Certified 14 (CE) Maximum Rated Persons Capacity
Dry Weight 6800LBS 3084KG Mass of boat with engine(s) and batteries, no fuel, water, waste, or gear
Max Power 560HP 418KW Maximum horsepower for safe operation
Standards & Options
Engine Option Standards and Options


Flooring Synthetic Wood StandardStandard
Toilet (Porta-Potti) StandardStandard
Vanity w/Solid Surface Top, Sink and Pullout Sprayer StandardStandard


Bimini Top W/Embroidered Boot StandardStandard


Cooler 48qt Carry-On StandardStandard
Courtesy Lighting, Blue/White, LED 12v StandardStandard
Drink Holders, Stainless Steel StandardStandard
Fiberglass Cockpit Liner with Non-Skid Drainage StandardStandard
Outlets 12v StandardStandard
Stereo Fusion Apollo Series Satellite Ready AM/FM Bluetooth w/ 4 JL Audio 6.5" Speakers with LED Lights & Dash Remote StandardStandard
Storage, In Floor w/Gas Assisted Hatch StandardStandard
Transom Shower (Cold Only) StandardStandard

Electrical System

Battery Charger w/Deck Plug StandardStandard
Battery Trays (2) StandardStandard
Panel, Battery Switch w/Emergency Parallel StandardStandard
Transom Tilt Switch StandardStandard

Engine Compartment

Automatic Bilge Pumps StandardStandard
Bilge Blower StandardStandard
Engine Compartment Lighting StandardStandard
Engine Hatch Electrically Actuated StandardStandard
Forced Air Ventilation w/Concealed Vents StandardStandard
Fire Extinguishing System, Automatic StandardStandard
Gel Coated Bilge and Engine Compartment StandardStandard

Fuel Systems

Double Clamped Fuel Lines StandardStandard


Storage, Accessory StandardStandard
Compass StandardStandard
Digital GPS Speedometer StandardStandard
Instrumentation with Fog Resistant Gauges (Digital) and Low Glare Night Lighting StandardStandard
MP3 Adapter StandardStandard
Outlet 12v w/USB StandardStandard
Steering Wheel, Leather Wrapped with Chromed Stainless Spokes StandardStandard
Steering Power Assisted StandardStandard
Steering Tilt StandardStandard
Trim Tab Indicators w/Auto Retract StandardStandard

Hull & Deck

Barrier Coat, Vinylester StandardStandard
Boarding Ladder, Telescoping and Recessed Bow StandardStandard
Bow and Stern Eyes, Stainless Steel, w/SS Backing Plate StandardStandard
Bow Plate, Stainless Steel StandardStandard
Bow Hand Rails, Stainless Steel StandardStandard
Cleats, Stainless Steel, Pull-Up (6) StandardStandard
Colored Hull Sides StandardStandard
Cooler Molded In, Bow StandardStandard
Custom Hull Side Graphics StandardStandard
Door, Walk-Thru at Helm StandardStandard
Door Walk-Thru At Transom StandardStandard
Drain Plug Brass Garboard StandardStandard
Horn, Electric Flush Mount StandardStandard
Lights, Navigation, LED StandardStandard
Lights, Docking StandardStandard
NMMA Certified StandardStandard
Rub Rail, Heavy Duty w/Stainless Steel Insert StandardStandard
Ski Tow, Stainless Steel StandardStandard
Storage, Anchor Fiberglass Hatch (Drains Overboard) StandardStandard
Storage Boxes, Fiberglass, Lighted w/Drink Holders StandardStandard
Storage Transom Wakeboard w/Gas Assisted Hatch and Dry Deck StandardStandard
Swim Platform, Molded in w/Telescoping Recessed Ladder and Hatch StandardStandard
Thru-Hulls, Stainless Steel Above Waterline StandardStandard
Transhield Shipping Cover StandardStandard
Windshield, Aluminum with Stainless Steel Header, Curved, and Tempered with Walk Thru StandardStandard


Aft Facing Seat - Starboard w/Slide-out Trash Receptacle StandardStandard
Aft Sunpad, Gas Assisted w/Aft Facing Flip-Up Bolster and Fiberglass Storage Compartment StandardStandard
Bow Seating with Fold Down Armrest and Molded in Cooler StandardStandard
L-Shaped Bench Seat w/Flip-Up Sunpad Extension StandardStandard
Helm Seat Port w/Flip-Up Thigh Rise and Fwd/Aft Facing Lounger StandardStandard
Helm Seat Starboard w/Flip-UpThigh Rise and Fold Down Arm Rest StandardStandard

Under Water Gear

Trim Tabs w/Indicators & Auto Retract StandardStandard


Bow and Cockpit Cover-Onyx Optional FeatureOptional
Bow and Cockpit Cover-Rio Optional FeatureOptional
Bow and Cockpit Cover-Royal Blue Optional FeatureOptional
Bow and Cockpit Cover-Sapphire Optional FeatureOptional
Bow and Cockpit Cover-Taupe Optional FeatureOptional
Bow Shade-Gray Optional FeatureOptional


Tower Cone Speakers, JL with 4 Channel Amplifier (Requires Stereo Upgrade Package & Arch Wakeboard Tower) Optional FeatureOptional
Cockpit Inlay, Terra (SeaDek) (Requires Swim Platform Inlay Option) Optional FeatureOptional
Cockpit Inlay, Gray (SeaDek) (Requires Swim Platform Inlay Option) Cockpit Inlay, Gray (SeaDek) (Requires Swim Platform Inlay Option) Optional FeatureOptional
Cockpit Drawer Refrigerator (DC Only) (Requires Wet Bar Option) Optional FeatureOptional
Cockpit Table, w/Pedestal and Vertical side Mount Bases Fwd. & Aft. Optional FeatureOptional
Sirius Satellite Package (Includes Antenna & Receiver) (Available for Domestic Customers Only) Optional FeatureOptional
Stereo Upgrade Package Premium Includes JL 10" Subwoofer & 5 Channel Amplifier Optional FeatureOptional
Stereo Remote (Stern) Optional FeatureOptional
Wet Bar w/Solid Surface Insert, Sink, Faucet,Trash Receptacle & Storage Optional FeatureOptional
Woven Cockpit Flooring Optional FeatureOptional


Toilet, Pump-out Deck Fitting Optional FeatureOptional
Electric Head System w/Holding Tank indicator & pump out deck fitting Optional FeatureOptional


Simrad GO7XSE GPS/Chartplotter/Sonar w/Transducer/Integrated Engine Functions & Depthsounder Optional FeatureOptional

Hull and Deck

Anchor Windlass Pre-Wire Optional FeatureOptional
Anchor Windlass w/Stainless Steel Anchor, Rope & Chain Optional FeatureOptional
Colored Hull Bottom (Other Than Arctic Ice) Optional FeatureOptional
Delete Graphics Optional FeatureOptional
Phender Pro Holders (4) Optional FeatureOptional
Removable Ski Tow Pylon Optional FeatureOptional
Swim Platform Inlay (SeaDek) (Terra) Optional FeatureOptional
Swim Platform Inlay (SeaDek) (Gray) Swim Platform Inlay (SeaDek) (Gray) Optional FeatureOptional
Underwater Lights, RGB LED Optional FeatureOptional
Wakeboard Tower, Electric, White Fiberglass with Ski Tow W/Aft Bimini Optional FeatureOptional
Wakeboard Tower, Electric, Black Fiberglass with Ski Tow W/Aft Bimini Optional FeatureOptional


Bow Filler Cushions Optional FeatureOptional

Waste Systems

Grey Water System For Porta Potti (N/A w/Macerator, Includes Pump Out Deck Fitting) Optional FeatureOptional
Grey Water System for Electric Head (N/A w/Macerator) Optional FeatureOptional
Macerator With Overboard Discharge (Requires Electric Head Option) Optional FeatureOptional
Engine Total HP Ratio Drive Prop Max MPH Range GPH @ Cruise MPH PDF
8.2 MAG MPI DTS CAT 380HP 2.0 Merc Bravo IIIX B3-22.5-SS 48-52 14@33 Download
8.2 MAG HO MPI DTS CAT 430HP 2.0 Merc Bravo IIIX B3-24-SS 50-54 14@34 Download
Twin 4.5L 250 DTS 500HP 2.20 Merc Bravo IIIX B3-24-SS 48-52 15.2@33 Download
Twin 4.5L 250 DTS AXIUS 500HP 2.20 Merc Bravo IIIX B3-24-SS 48-52 15.2@33 Download
Twin 4.5L 250 DTS SEACORE 500HP 2.20 Merc Bravo IIIX B3-24-SS 48-52 15.2@33
Twin 4.5L 250 DTS AXIUS SEACORE 500HP 2.20 Merc Bravo IIIX B3-24-SS 48-52 15.2@33
Twin 4.5L 250 CAT DTS 500HP 2.20 Merc Bravo IIIX B3-24-SS 48-52 15.2@33 Download
Twin 4.5L 250 CAT DTS AXIUS 500HP 2.20 Merc Bravo IIIX B3-24-SS 48-52 15.2@33 Download
Twin 4.5L 250 CAT DTS SEACORE 500HP 2.20 Merc Bravo IIIX B3-24-SS 48-52 15.2@33
Twin 4.5L 250 CAT DTS AXIUS SEACORE 500HP 2.20 Merc Bravo IIIX B3-24-SS 48-52 15.2@33

Showing 1 to 4 of 4 entries
*Consult your local dealer for catalyst engine requirements for your region.
