M6
NAP PRICE STARTING AT $97,687.00
Setting A New Standard
NAP PRICE STARTING AT $97,687.00
Luxurious Multitasker

The M6 has everything you’ll need to enjoy a full day of cruising, skiing, wakeboarding and tubing. Featuring spacious seating and storage options, a head compartment, two recessed and telescoping boarding ladders located in the bow and stern, and a Fusion satellite ready AM/FM stereo, you'll have everything you need to enjoy your time out on the water. With the standard signature graphics and colored hull, you’re sure to have one of the sharpest boats on the water.  The M6 is style, luxury and performance personified!

LOA W/SWIM PLATFORM
25'10"
BEAM
8'6"
FUEL CAPACITY
80GAL
MAX HORSEPOWER
430HP
Build Your Custom Monterey M6

Design a Monterey vessel that’s truly a one-of-a-kind masterpiece and know there will never be someone out on the water like you.

Begin My Build
M6
Photo Gallery
A Study In Luxury
Monterey In Motion
Capturing Performance, Speed, And Luxury
A Work Of Art Is Best Viewed In Person
Specifications Review
Specifications
Spec US Unit Metric Unit Description
LOA W/Swim Platform 25' 10" 7.87M Length Overall, including add-on swim platform, not including bow rail or anchor roller
Beam 8' 6" 2.59M Width of hull at widest section including rubrail
Deadrise 20° 20° Angle of keel measured at transom
Draft - Stern Drive Up 22" 55.9CM Depth of hull to lowest point, stern drive trimmed up
Draft - Stern Drive Down 36" 91.4CM Depth of hull to bottom of stern drive, trimmed down
Bridge Clearance W/Tower 8' 2.4M Height from water to highest point on tower, normal load
Fuel Capacity 80GAL 302.8L Capacity of fuel tank in gallons/liters
Water Capacity 15GAL 56.8L Capacity of water tank in gallons/liters
Waste Capacity 11GAL 41.6L Capacity of waste tank in gallons/liters
Dry Weight 5,200LBS 2,359KG Mass of boat with engine(s) and batteries, no fuel, water, waste, or gear
Max Persons 15 (US) 13 (CE) Maximum Rated Persons Capacity
Max Persons Weight 2475LBS 975KG Maximum capacity of people that can be safely carried in pounds/kilograms
Max Persons/Gear Weight 2715LBS 1030KG Maximum capacity of people and gear that can be safely carried in pounds/kilograms
Max Power 430HP 321KW Maximum horsepower for safe operation
Standards & Options
Engine Option Standards and Options

Canvas

Bimini Top w/Embroidered Boot StandardStandard

Cockpit

Cockpit Table w/ Pedestal & Vertical Side Mount Bases, Fwd & Aft StandardStandard
Cooler, 48 Qt Carry-On StandardStandard
Courtesy Lighting, Blue/White, LED 12 V StandardStandard
Drink Holders, Stainless Steel (13) StandardStandard
Fiberglass Cockpit Liner w/Non-Skid & Drainage StandardStandard
Grab Rails StandardStandard
Outlet, 12 V StandardStandard
Stereo, Fusion Satellite Ready AM/FM/BLUETOOTH w/built-in iPod Dock & (4) Rockford Fosgate 6.5" Speakers & Dash Remote StandardStandard
Storage, In-Floor Ski w/Gas Assisted Hatch Cover & Dry Deck StandardStandard
Storage, Starboard Helm StandardStandard
Transom Shower w/Pressurized Water (Cold Only) StandardStandard

Electrical Systems

Battery Switch, Dual w/2 Battery Trays StandardStandard
Weatherproof Electrical System w/Individual Circuit Protection StandardStandard
Transom Tilt Switch StandardStandard

Engine Compartment

Automatic Bilge Pump StandardStandard
Bilge Blower StandardStandard
Engine Hatch, Electrically Actuated StandardStandard
Fire Port StandardStandard
Forced Air Ventilation w/Concealed Vents StandardStandard
Gel Coated Bilge & Engine Compartment StandardStandard

Fuel Systems

Double Clamped Fuel Lines StandardStandard

Head

Toilet (Porta-Potti) StandardStandard
Vanity w/Solid Surface Top, Sink & Pullout Sprayer StandardStandard
Flooring, EVA Foam StandardStandard

Helm

Compass StandardStandard
Digital GPS Speedometer StandardStandard
Instrumentation w/Fog Resistant Gauges (Digital) & Low Glare Night Lighting StandardStandard
MP3 Adapter StandardStandard
Outlet, 12 V USB StandardStandard
Steering Wheel, Black w/Silver Insert StandardStandard
Steering, Power Assisted StandardStandard
Steering, Tilt StandardStandard
Switches, Lighted Weatherproof StandardStandard

Hull & Deck

Air Assist Chine StandardStandard
Barrier Coat, Vinylester StandardStandard
Boarding Ladder, Telescoping & Recessed, Bow StandardStandard
Bow & Stern Eyes, Stainless Steel, w/SS Backing Plate StandardStandard
Bow Hand Rails, Stainless Steel StandardStandard
Bow Plate, Stainless Steel StandardStandard
Cleats, Pull-up, Stainless Steel (6) StandardStandard
Colored Hull StandardStandard
Cooler Molded In, Bow StandardStandard
Custom Hull Side Graphics StandardStandard
Door, Walk-Thru at Helm StandardStandard
Door, Walk-Thru at Transom StandardStandard
Drain Plug, Brass Garboard StandardStandard
Horn, Electric Flush Mount StandardStandard
Lights, Docking StandardStandard
Lights, Navigation, LED StandardStandard
NMMA Certified StandardStandard
Rub Rail, Heavy Duty w/Stainless Steel Insert StandardStandard
Ski Tow, Stainless Steel StandardStandard
Storage, Anchor w/Fiberglass Hatch (Drains Overboard) StandardStandard
Storage, Transom Wakeboard w/Gas Assisted Hatch & Dry Deck StandardStandard
Swim Ladder, Telescoping & Recessed, Stern w/Fiberglass Hatch StandardStandard
Swim Platform, Integral StandardStandard
Thru Hulls, Stainless Steel Above Waterline StandardStandard
Transhield Cover StandardStandard
Windshield, Curved Tempered w/Walk-Thru, Onyx Framed StandardStandard

Seating

Aft Back To Back L-Lounge w/ Fiberglass Bases & Sun Pad Conversion w/Recliner, Electrically Actuated StandardStandard
Aft Facing Seat, Starboard W/Carry-on Slide-Out Cooler StandardStandard
Aft Transom Seating StandardStandard
Bow Seating w/Fold Down Arm Rest StandardStandard
Bucket Seat, Swivel w/Slider & Flip-Up Bolster, Port & Starboard StandardStandard
Seat Cushions w/Storage Compartments, Bow StandardStandard

Canvas

Bow and Cockpit Cover-Onyx Optional FeatureOptional
Bow and Cockpit Cover-Rio Optional FeatureOptional
Bow and Cockpit Cover-Royal Blue Optional FeatureOptional
Bow and Cockpit Cover-Sapphire Optional FeatureOptional
Bow and Cockpit Cover-Taupe Optional FeatureOptional

Cockpit

Cockpit Inlay, Terra (SeaDek) (Requires Swim Platform Inlay Option) Cockpit Inlay, Terra (SeaDek) (Requires Swim Platform Inlay Option) Optional FeatureOptional
Cockpit Inlay, Gray (SeaDek) (Requires Swim Platform Inlay Option) Cockpit Inlay, Gray (SeaDek) (Requires Swim Platform Inlay Option) Optional FeatureOptional
Forward Shower w/Pressurized Water (Cold Only) Optional FeatureOptional
Premium Stereo Upgrade Includes (4) 6.5" Rockford Fosgate M2 Speakers w/integrated LED Lights,10" Punch Subwoofer & 5 Channel Amplifier Optional FeatureOptional
Stern Mounted Stereo Remote Optional FeatureOptional
Swim Platform Inlay, Terra (SeaDek) Swim Platform Inlay, Terra (SeaDek) Optional FeatureOptional
Swim Platform Inlay, Gray (SeaDek) Swim Platform Inlay, Gray (SeaDek) Optional FeatureOptional
Tower Cone Speakers, Rockford Fosgate, w/ 2 Channel Amp (Requires Stereo Upgrade Package and Wakeboard Tower) Optional FeatureOptional
Wet Bar w/Solid Surface Insert, Sink, Faucet, Slide-Out Carry-On Cooler & Storage (In Lieu of Standard Aft Seat) Optional FeatureOptional
Woven Cockpit Flooring Optional FeatureOptional

Engine Compartment

Battery Charger w/Deck Plug (Standard in Australia) Optional FeatureOptional
Fire Extinguishing System (Domestic Only) (Standard in EU Countries & Australia) Optional FeatureOptional

Head

Toilet, Pump-out Deck Fitting Optional FeatureOptional
Electric Head System w/Holding Tank Optional FeatureOptional

Helm

Simrad NSX Series GPS/Chartplotter/Sonar w/Transducer/Integrated Engine Functions, and Depthsounder Optional FeatureOptional

Hull & Deck

Anchor Windlass Pre-Wire Optional FeatureOptional
Anchor Windlass w/Anchor Rope & Chain Optional FeatureOptional
Colored Hull Bottom (Other Than Arctic Ice) Optional FeatureOptional
Delete Graphics Optional FeatureOptional
Phender Pro (4) Optional FeatureOptional
Portlight, In Head, w/Screen Optional FeatureOptional
Removable Ski Tow Pylon Optional FeatureOptional
Underwater Lights, RGB LED Optional FeatureOptional
Wakeboard Tower, Black (Includes Wakeboard Bimini) Optional FeatureOptional
Wakeboard Tower, White (Includes Wakeboard Bimini) Optional FeatureOptional

Seating

Filler Cushion, Bow Optional FeatureOptional
Portside Forward/Aft Facing Lounger Optional FeatureOptional

Under Water Gear

Trim Tabs W/Indicators & Auto Retract Optional FeatureOptional

Waste Systems

Grey Water System for Porta Potti (N/A With Macerator) Optional FeatureOptional
Macerator w/Overboard Discharge (requires Electric Head Option) Optional FeatureOptional
Grey Water System For Electric Head (N/A With Macerator) Optional FeatureOptional
Performance
Engine Total HP Ratio Drive Prop Max MPH Range GPH @ Cruise MPH PDF
*6.2L 300 DTS 300HP 2.20 BR III B3-24-SS 43-47 14@35E
6.2L 300 CAT DTS 300HP 2.20 BR III B3-24-SS 43-47 14@35E
*6.2L 350 DTS 350HP 2.20 BR III B3-26-SS 50-54 10.4@32 Download
6.2L 350 CAT DTS 350HP 2.20 BR III B3-26-SS 50-54 10.4@32 Download

Showing 1 to 4 of 4 entries
*Consult your local dealer for catalyst engine requirements for your region.
